Construction:
Tube: Inner tube of oil resistant synthetic rubber.
Reinforcement: Two braids of suitable fiber.
Cover: An oil and weather resistant synthetic rubber.
Temperature: -40 °C to +100°C (-40 ℉ to +212 ℉)
Introduction:
SAE 100R3 double fiber braid hydraulic rubber hose is ideal for medium pressure fuel and oil lines as well as return and suction hoses of hydraulic systems. Two plies of braided textile protect the inner tube in case that the outside cover is broken. Nitrile tube has premium oil resistant and won't react with petroleum- or water-based hydraulic fluids within -40°C to 100°C.
SAE 100R3 | ||||||||||||||
Type | Size | I.D | O.D | Max W.P | P.P | Min B.P | Min B.R | Weight | ||||||
| mm | inch | min | max | min | max | Mpa | Psi | Mpa | Psi | Mpa | Psi | mm | kg/m | |
| R3-03 | 5 | 3/16 | 4.5 | 5.4 | 11.9 | 13.5 | 10.5 | 1520 | 21 | 3050 | 42 | 6090 | 75 | 0.16 |
| R3-04 | 6.3 | 1/4 | 6.1 | 7.0 | 13.5 | 15.1 | 8.7 | 1260 | 17.5 | 2540 | 35 | 5075 | 75 | 0.18 |
| R3-05 | 8 | 5/16 | 7.6 | 8.5 | 16.7 | 18.3 | 8.4 | 1220 | 16.8 | 2440 | 33.5 | 4860 | 100 | 0.27 |
| R3-06 | 10 | 3/8 | 9.2 | 10.1 | 18.3 | 19.8 | 7.8 | 1130 | 15.7 | 2280 | 31.5 | 4570 | 100 | 0.31 |
| R3-08 | 12.5 | 1/2 | 12.4 | 13.5 | 23.0 | 24.6 | 7 | 1015 | 14 | 2030 | 28 | 4060 | 125 | 0.45 |
| R3-10 | 16 | 5/8 | 15.6 | 16.7 | 26.2 | 27.8 | 6.1 | 885 | 12.2 | 1770 | 24.5 | 3550 | 140 | 0.53 |
| R3-12 | 19 | 3/4 | 18.7 | 19.8 | 31.0 | 32.5 | 5.2 | 750 | 10.5 | 1520 | 21 | 3045 | 150 | 0.72 |
| R3-16 | 25 | 1 | 25.1 | 26.2 | 36.9 | 39.3 | 3.9 | 570 | 7.8 | 1130 | 15.7 | 2280 | 205 | 0.90 |
| R3-20 | 31.5 | 1 1/4 | 31.4 | 32.9 | 42.9 | 46.0 | 2.6 | 380 | 5.2 | 750 | 10.5 | 1520 | 250 | 1.07 |
